Development Kits
Altera and Partner Development Kits
Product and Vendor Name
ProcHILs
GiDEL
Cyclone V GT FPGA
Development Kit
Altera
Cyclone V E FPGA
Development Kit
Altera
Cyclone IV GX FPGA
Development Kit
Altera
Arria II GX FPGA
Development Kit, 6G Edition
Altera
Arria II GX FPGA
Development Kit
Altera
Arria V GX FPGA Development Kit,
Arria V GX Edition
Altera
Arria V GX Starter Kit,
Arria V GX Edition
Altera
Transceiver Signal Integrity Kit,
Stratix IV GX Edition
Altera
Device
Stratix V
Stratix IV
Cyclone V GT
5CGTFD9E5F35C7N
Cyclone V E
5CEFA7F31C7N
Cyclone IV GX
EP4CGX150DF31C7N
Arria II GX
EP2AGX125F1152
Arria II GX
EP2AGX125F1152
Arria V GX
5AGXFB3H6F40C6N
Arria V GX
5AGXFB3H4F35C4
Stratix IV GX
EP4SGX230F1517
Description
This development kit provides a state-of-the-art Hardware in the Loop
acceleration tool for running Simulink designs on Altera’s FPGAs. ProcHILs can
automatically translate Simulink designs built using Altera’s DSP Builder into
FPGA code and run this code under Simulink. The generated code is compatible
with the Proc board installed on the target PC and has the synchronization code
needed to communicate with Simulink via PCIe.
This kit can be used to prototype Cyclone V GT FPGA or Cyclone V GX FPGA
applications. It offers a quick and simple way to develop low-cost and low-power
system-level designs and achieve rapid results. This kit supports a myriad of
functionalities, such as FPGA prototyping, FPGA power measurement, transceiver
I/O performance up to 5 Gbps, PCIe Gen2 x4 (at 5 Gbps per lane), endpoint or
rootport support.
The Cyclone V E Development Kit offers a comprehensive general-purpose
development platform for many markets and applications, including industrial,
networking, military, and medical applications. The kit features an Altera Cyclone
V device and a multitude of onboard resources including multiple banks of DDR3
and LPDDR2 memory, LCD character display, LEDs, user switches, USB, and RJ-45
connectors. The Cyclone V E Development Kit gives industrial equipment
designers greater flexibility in implementing real-time Ethernet communications
with Industrial Ethernet IP cores.
This kit provides a comprehensive design environment that allows you to quickly
develop low-cost and low-power FPGA system-level designs. This kit includes the
PCIe short card form factor, two HSMC connectors, and a 10/100/1000 Mbps
Ethernet interface. Onboard memory includes 128 MB DDR2 SDRAM, 64 MB flash,
and 4 MB SSRAM. This kit also includes SMA connectors, and 50 MHz,
100 MHz, and 125 MHz clock oscillators, as well as user interfaces including push
buttons, LEDs, and a 7-segment LCD display.
This kit provides a full-featured hardware development platform for prototyping
and testing high-speed serial interfaces to an Arria II GX FPGA up to 6 Gbps. This
kit includes the PCIe x8 form factor, one HSMC connector, 128 MB 16 bit DDR3
SDRAM device, 1 GB 64 bit DDR2 SODIMM, 2 MB SSRAM, and 64 MB flash.
This kit provides a full-featured hardware development platform for prototyping
and testing high-speed serial interfaces to an Arria II GX FPGA. This kit includes the
PCIe x8 form factor, one HSMC connector, 128 MB 16 bit DDR3 SDRAM device,
1 GB 64 bit DDR2 SODIMM, 2 MB SSRAM, and 64 MB flash.
This kit provides a full-featured hardware development platform for prototyping
and testing high-speed serial interfaces to an Arria V GX FPGA. This kit includes
two Arria V 5AGXFB3H6F40C6N FPGAs, the PCIe x8 form factor, two HSMC
connectors, one FPGA mezzanine card (FMC) connector, 1,152 MB 72 bit DDR3
SDRAM, 4 MB 36 bit QDR II+ SRAM, flash memory, and two additional 32 bit
DDR3 SDRAM devices. This kit also includes SMA connectors and a bull’s-eye
connector for differential transceiver I/Os.
This kit provides a low-cost platform for developing transceiver I/O-based Arria V
GX FPGA designs. This kit includes the PCIe x8 form factor, one HSMC connector, a
32 bit DDR3 SDRAM device, one-channel high-speed transceiver input and output
connected to SMAs, HDMI output, SDI input and output, 16x2 LCD display, and
flash memory.
This kit features eight full-duplex transceiver channels with SMA connectors,
156.25 MHz, 155.52 MHz, 125 MHz, 100 MHz, and 50 MHz clock oscillators, six
user push buttons, eight dual in-line package (DIP) switches, eight user LEDs, a
7-segment LCD display, power and temperature measurement circuitry, and
Ethernet, USB, and JTAG ports.
68
Altera Product Catalog
?
2013
?
www.altera.com
